An Attractive and Reliable All Purpose Metal Panel
This versatile, all purpose metal panel has long served customers with lasting durability and a pleasing appearance. M-Loc® boasts a sturdy design and provides resistance to the most severe weather.
It is an excellent choice when the project requires a commercial-strength panel with a low-rib appearance. Additionally, M-Loc can be used on roofing, siding, and is popular for metal building projects.
APPLICATION: Roofing, Siding, Interior Projects, Buildings
FASTENER SYSTEM: Exposed
ROOF PITCH (minimum): 1:12
GAUGE: 26 gauge | 24 gauge*
PANEL COVERAGE WIDTH: 36″
RIB HEIGHT: 13/16″
DISTANCE FROM RIB-TO-RIB: 6″
STEEL THICKNESS: 26 ga. 0.0185″ | 24 ga. 0.0230″
PAINT THICKNESS
- Top coat paint: .70 mil
- Top coat primer: .30 mil
- Bottom coat backer: .35 mil
- Bottom coat primer: .35 mil
TOTAL THICKNESS: 26 ga. 0.0202″ | 24 ga. 0.0247″
RUST PROTECTANT SUBSTRATE: Galvalume AZ50
STEEL STRENGTH: 80,000 PSI (26 ga.) | 50,000 PSI (24 ga.)
PAINT SYSTEM: SMP
TEXTURED COLORS AVAILABLE: No
WARRANTY
- Lifetime limited paint adhesion
- 30-yr. chalk and fade
- 50-yr. Galvalume perforation
*24 ga. available in Polar and Galvalume (acrylic-coated bare) in select plants
When considering the best panel for your project, keep in mind the many benefits of this versatile option. With its exceptional durability and attractive appearance, M-Loc is a reliable choice that can withstand even the harshest weather conditions. Additionally, its low-rib design is perfect for commercial projects that require both aesthetic appeal and commercial-grade strength.
- Available in 26 gauge with a coverage area of 36-inches.
- Full-bearing sidelap rib provides consistent weather-resistant joint.
- M-Loc is a structural roof and wall panel that can be installed directly over purlins, joists, or solid decking.
- Recommended for 1:12 or greater roof slopes.
- This panel is produced in our Cedar Hill, TX, and Mount Airy, NC, facilities. Longer lead times may apply.
- Optional DripX condensation control for heightened protection.
When you buy metal roofing, siding, or buildings from us, you can be assured that your new investment will look great for a lifetime. Our warranties cover you in unexpected times. We offer a variety of warranties, depending on the material and panel profile you choose.
M-Loc comes with a Limited Lifetime warranty helping protect your investment in home or business.
