Standing Seam Panels with Easy Installation
Central-Loc® is a versatile standing seam panel system and is designed for commercial low slope applications. Not only is it a durable and economical solution for both commercial and industrial projects but also the Central-Loc profile has a snap lock-joint for ease of installation.
In addition, floating clips allow for thermal roof expansion and contraction during extreme temperature changes and factory-applied sealant ensures a secure, weather-tight lap.
APPLICATION: Roofing and Buildings
FASTENER SYSTEM: Hidden
ROOF PITCH (minimum): 1/4:12
GAUGE: 24 gauge
PANEL COVERAGE WIDTH: 18″ or 24″
DISTANCE FROM RIB-TO-RIB: 18″ or 24″
RIB HEIGHT: 3″
STEEL THICKNESS: 0.023″
PAINT THICKNESS
- Top coat paint: .70 mil
- Top coat primer: .30 mil
- Bottom coat backer: .35 mil
- Bottom coat primer: .20 mil
TOTAL THICKNESS: 0.02455″
RUST PROTECTANT SUBSTRATE: Galvalume AZ50
STEEL STRENGTH: 50,000 PSI min
PAINT SYSTEM: Fluropon
TEXTURED COLORS AVAILABLE: No
WARRANTY
- Lifetime limited paint adhesion
- 30-yr. chalk and fade
- 50-yr. Galvalume perforation
Central-Loc® is a snap-together trapezoidal roofing system. It is a durable and economical standing seam profile, ideal for commercial and industrial applications. Its snap lock-joint enables easy installation, while floating clips allow for thermal roof expansion and contraction during extreme temperature changes. Additionally, large 3″ ribs and factory applied sealant ensure a weather-tight seal on slopes as low as 0.25:12.
- Central-Loc comes in 24 gauge with 18 or 24″ coverage.
- Self-engaging backup plates and optional pre-punched panels and for ease of installation.
- UL580 class 90 uplift approved and is ASTM tested for both air and water infiltration.
- Add DripX® for condensation control and vapor barrier elimination.
- Can be used for both new construction and retrofit.
- Manufactured from Galvalume which offers two to four times the corrosion resistance of galvanized steel.
- Panels are factory notched for ease of installation at the endlap.
- Reversible end-for-end panels so each side of the roof can be installed simultaneously.
When you buy metal roofing, siding, or buildings from us, you can be assured that your new investment will look great for a lifetime. Our warranties cover you in unexpected times. We offer a variety of warranties, depending on the material and panel profile you choose.
Central-Loc comes with a Limited Lifetime warranty helping protect your investment in home or business.
