Built to Last. Built Quick.
Centra Series™ bolt-up metal buildings go up quickly and easily. They are engineered for easy assembly with no welding needed on-site.
INSTALLATION GUIDE
- Easy to follow assembly instructions and construction plans
- Installation videos available
FRAMING (MINIMUM)
- 8″ 16 gauge, red iron roof purlin, flush wall girts, eave struts, and endwall columns
- 8″ 14 gauge, red iron sidewall column and rafter
- 14 gauge, red iron base angle
- 3/8″ thick steel structural plates
- Universal bolt package for simple installation
ROOF
- Prime, 26-gauge acrylic Galvalume R-Loc® with CentralGuard® Protection—3:12 pitch
WALLS
- Prime, 26-gauge painted R-Loc with CentralGuard Protection
TRIM
- Painted 26 gauge trim package includes base, rake, formed ridgecap, corners, eave and peak box trims
OPENING
- 10’ wide x 7′, 8′, 9′ or 10′ high framed opening at one endwall *
- Door trim package includes painted jamb/header and jamb cover trim.
*10′ high framed openings are available on 12′ height building packages only. **20×24 Sidewall openings are 9’ wide. All others are 10’ wide.
ACCESSORIES
- Roof and wall closures
- Butyl tape
- Clear sealant
- 1-1/2″ structural A325 bolts and nuts
- 1-1/4″ masonry drive-in anchor for base condition
- 1-1/4″ self-drilling fasteners
- 1-1/4″ A307 fin neck bolts and nuts
- 7/8″ lap fasteners
- Pop rivets
- 3070 steel walk door, jamb and lever lockset
WARRANTY
- Lifetime limited paint warranty on painted panels
- 25-yr. perforation warranty on unpainted panels
Centra Series bolt-up metal buildings are your steel building go-to option for a quick and easy assembly without any welding needed on-site. We manufacture the components in-house, so your order is ready for pick-up / delivery quick. Centra Series is available in 8 different sizes, with custom accessories available to create a unique and beautiful look on your property.
- Fast turn-around
- Assembly instructions included with package
- Framing members included with no on-site welding required!
- (1) 3′ wide x 7′ high walk-in door included
- Building bolts, fasteners, tape, and sealant
- Flexible framed opening heights (7′, 8′, 9′, or 10′)*
- Many options and accessories
Sizes:
- 20w X 24l X 10h
- 20w X 24l X 12h
- 24w X 30l X 10h
- 24w X 30l X 12h
- 30w X 40l X 10h
- 30w X 40l X 12h
- 30w X 52l X 10h
- 30w X 52l X 12h
*10′ height framed openings are available on 12′ height building packages only.
Centra Series buildings come with a Limited Lifetime warranty due to the R-Loc panel on the walls and roof.
