A Timeless Look with Quality Metal
This time-honored board and batten siding profile gets an upgrade with hidden fasteners. Metal Board & Batten siding is a contemporary and durable exterior cladding option that adds a touch of modern sophistication to residential and commercial buildings alike.
With Board & Batten, you get a lifetime of beauty at a price that’s comparable to wooden panel installation, but without the need for ongoing maintenance found in perishable wooden or vinyl siding. Board and Batten exterior siding is a versatile option for architectural creativity.
APPLICATION: Siding, Interior Projects, Buildings
FASTENER SYSTEM: Hidden
GAUGE: 26 gauge
PANEL COVERAGE WIDTH: 10″
RIB HEIGHT: 3/4″
SMP / TEXTURED
STEEL THICKNESS: 0.0185 inches
PAINT THICKNESS
- Top coat paint: .70 mil
- Top coat primer: .30 mil
- Bottom coat backer: .20 mil
- Bottom coat primer: .30 mil
RUST PROTECTANT SUBSTRATE: Galvalume AZ50
STEEL STRENGTH: 50,000 PSI min
PAINT SYSTEM: SMP
TEXTURED COLORS AVAILABLE: Yes
WARRANTY
- Lifetime limited paint adhesion
- 30-yr. chalk and fade
- 50-yr. Galvalume perforation
WOODGRAIN
STEEL THICKNESS: 0.0185 inches
RUST PROTECTANT SUBSTRATE: Galvalume AZ50
STEEL STRENGTH: 50,000 PSI min.
COATING SYSTEM: Direct print
WARRANTY
- 20-yr. digital print
- 20-yr. chalk and fade
- 40-yr. Galvalume perforation
With Board & Batten, you get a lifetime of beauty at a price that’s comparable to wooden panel installation, but without the need for ongoing maintenance found in perishable wooden or vinyl siding.
- Available in 26 gauge and 10″ width coverage.
- Features alternating wide boards (metal panels) with narrow, thin strips of metal (the battens) that are placed over the seams where the two pieces meet.
- This style was historically used on barns and farmhouses, and is now popular in both residential and commercial construction.
- Hidden fastener installation ensures clean lines and a stylish finish. Vertical wall applications only.
- The steel is up to 80% recycled content and, as the most recycled material on the planet, the choice to install steel rather than vinyl is environmentally responsible.
When you buy metal roofing, siding, or buildings from us, you can be assured that your new investment will look great for a lifetime. Our warranties cover you in unexpected times. We offer a variety of warranties, depending on the material and panel profile you choose.
Board & Batten comes with a Limited Lifetime warranty for Textured and SMP and a 20-year warranty for direct print options, helping protect your investment in home or business.
